MOLEX 76861-1000
MOLEX 76861-1000

MOLEX 76861-1000

Manufacturer No:

76861-1000

Manufacturer:

MOLEX

Package:

Description:

Female Black 787.4?m NOT SPECIFIED 2 Rows Press-Fit 46 Positions

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

76861-1000 information

MOLEX 76861-1000 technical specifications, attributes, parameters and parts with similar specifications to MOLEX 76861-1000.

  • Type
  • Parameter
  • Factory Lead Time
  • 8 Weeks
  • Contact Material
  • NOT SPECIFIED
  • Contact Plating
  • Gold
  • Mount
  • Through Hole
  • Insulation Material
  • Glass
  • Housing Material
  • Glass fibre
  • Published
  • 2013
  • Part Status
  • Active
  • Termination
  • Press-Fit
  • ECCN Code
  • EAR99
  • Connector Type
  • BOARD CONNECTOR
  • Number of Positions
  • 46
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -40°C
  • Color
  • Black
  • Number of Rows
  • 2
  • Gender
  • Female
  • Voltage - Rated
  • 250V
  • HTS Code
  • 8536.69.40.40
  • Subcategory
  • Headers and Edge Type Connectors
  • Contact Finish - Mating
  • NOT SPECIFIED
  • Pitch
  • 787.4?m
  • Total Number of Contacts
  • 46
  • Orientation
  • Straight
  • Number of Conductors
  • ONE
  • Reference Standard
  • UL,CSA,TUV
  • Voltage - Rated AC
  • 250V
  • Reliability
  • COMMERCIAL
  • Number Of PCB Rows
  • 4
  • Body Depth
  • 0.485 inch
  • Contact Style
  • BELLOWED TYPE
  • Contact Resistance
  • 60mOhm
  • Insulation Resistance
  • 5000000000Ohm
  • Body/Shell Style
  • RECEPTACLE
  • ELV
  • Compliant
  • Max Voltage Rating (AC)
  • 250V
  • Dielectric Withstanding Voltage
  • 1500VDC V
  • Contact Pattern
  • RECTANGULAR
  • Halogen Free
  • Low Halogen
  • Length
  • 39.09mm
  • Width
  • 7.31mm
  • Plating Thickness
  • 30?in
  • Card Thickness
  • 1.6002mm
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-0

Download datasheets and manufacturer documentation for MOLEX 76861-1000.

Datasheets:

76861-1000 Overview


Using the connector socket BOARD CONNECTOR is the device's method of connection.The maximum operating temperature of 85°C°C allows for stable operation.A minimum working temperature of -40°C degrees Celsius is required to ensure its reliability.

76861-1000 Features




76861-1000 Applications
