Microchip AT28BV256-20SU

Manufacturer No:

AT28BV256-20SU

Manufacturer:

Microchip

Package:

28-SOIC (0.295, 7.50mm Width)

Description:

Battery-Voltage 256Kbit (32Kbit x 8) Parallel EEPROM with Software Data Protection

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AT28BV256-20SU information

Microchip AT28BV256-20SU technical specifications, attributes, parameters and parts with similar specifications to Microchip AT28BV256-20SU.

Type
Parameter

Battery Backup
No

Density
256 Kbit

Endurance
10,000

Max. Clock Freq.
0

Operating Voltage Max (V)
3.6

Operating Voltage Min (V)
2.7

Page Size (Bytes)
0

Write Protected
No

Data Retention
10

Read Access Speed
200 ns

Download datasheets and manufacturer documentation for Microchip AT28BV256-20SU.

The Microchip AT28BV256 is a high-performance 256Kbit Parallel EEPROM offering access times to 200ns with 54mW power dissipation and 2.7V supply voltage. Deselected, CMOS standby current is less than 20µA. Access like static RAM for the read or write cycle without external components; it contains a 64-byte page register to allow writing of up to 64 bytes simultaneously. Optional Software Data Protection mechanism guards against inadvertent writes; and an extra 64 bytes of EEPROM enables device identification or tracking.

32 Kbits x 8 (256 Kbit)
2.7V to 3.6V Supply
Parallel Interface
200ns access time
Self-Timed Erase and Write Cycles (10 ms max)
Page Write and Byte Write
Data Polling for end of write detection
Low Power Consumption
Read / Write current 15 mA (Max)
Standby current 20 µA (Typ), 50 µA (Max)
Write-Protection
Hardware Protection
Software Data Protect
More than 100,000 erase/write cycles
Data retention > 10 years
Temperature Ranges
Standard Temperature Range: -40°C to 85°C
Available in Green (Pb/Halide-free) Packaging Only
32-lead, Plastic J-leaded Chip Carrier (PLCC)
28-lead, 0.300" Wide, Plastic Gull Wing Small Outline (SOIC)
28-lead, Plastic Thin Small Outline Package (TSOP)
