TI CC2420RTCR

Manufacturer No:

CC2420RTCR

Manufacturer:

Package:

48-VFQFN Exposed Pad

Description:

TxRx Only 2.4GHz 2.1V~3.6V SPI 250kbps 18.8mA - Receiving 8.5mA~17.4mA - Transmitting DSSS, O-QPSK 48-VFQFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

CC2420RTCR information

TI CC2420RTCR technical specifications, attributes, parameters and parts with similar specifications to TI CC2420RTCR.

Type
Parameter

Contact Plating
Gold

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
48-VFQFN Exposed Pad

Number of Pins
48

Operating Temperature
-40°C~85°C

Packaging
Tape & Reel (TR)

JESD-609 Code
e4

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
48

Type
TxRx Only

HTS Code
8542.39.00.01

Subcategory
Other Telecom ICs

Technology
CMOS

Voltage - Supply
2.1V~3.6V

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
1.8V

Terminal Pitch
0.5mm

Frequency
2.4GHz

Base Part Number
CC2420

Pin Count
48

Qualification Status
Not Qualified

Power Supplies
1.81.8/3.3V

Nominal Supply Current
17.4mA

Protocol
Zigbee®

Power - Output
0dBm

RF Family/Standard
802.15.4

Data Rate (Max)
250kbps

Serial Interfaces
SPI

Current - Receiving
18.8mA

Current - Transmitting
8.5mA~17.4mA

Modulation
DSSS, O-QPSK

Sensitivity (dBm)
-95 dBm

Length
7mm

Height Seated (Max)
0.9mm

Width
7mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for TI CC2420RTCR.

CC2420RTCR Overview

Space is saved using RF transceiver IC's 48-VFQFN Exposed Pad package. The RF transceiver's mounting is mounted using Surface Mount.When transceiver RF emerges as a TxRx Only, it performs extremely well and is highly reliable.High reliability is achieved with advanced transceiver RF' packaging Tape & Reel (TR).A transceiver RF circuit board with 48 pins is designed.Try searching for the transceiver with CC2420 if you are looking for variants.Surface Mount mounts transceiver on the wall.The frequency of 2.4GHz is used as the basis for RF transceivers operation.
