Manufacturer No:

HDG104-DN-2

Manufacturer:

H&D Wireless AB

Package:

44-LQFN Exposed Pad Module

Description:

TxRx + MCU 2.4GHz 2.75V~3.6V SDIO, SPI, UART 54Mbps 60mA - Receiving 15mA - Transmitting 16QAM, 64QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK 1kB EEPROM 160kB SRAM 44-LQFN Exposed Pad Module

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HDG104-DN-2 information

H&D Wireless AB HDG104-DN-2 technical specifications, attributes, parameters and parts with similar specifications to H&D Wireless AB HDG104-DN-2.

  • Type
  • Parameter
  • Factory Lead Time
  • 14 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 44-LQFN Exposed Pad Module
  • Number of Pins
  • 44
  • Supplier Device Package
  • 44-QFN SIP (7.7x7.1)
  • Weight
  • 75.891673mg
  • Operating Temperature
  • -20°C~70°C
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2009
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 6 (Time on Label)
  • Type
  • TxRx + MCU
  • Max Operating Temperature
  • 70°C
  • Min Operating Temperature
  • -20°C
  • Voltage - Supply
  • 2.75V~3.6V
  • Depth
  • 7.1mm
  • Frequency
  • 2.4GHz
  • Operating Supply Voltage
  • 3.3V
  • Interface
  • Serial
  • Max Supply Voltage
  • 3.6V
  • Min Supply Voltage
  • 3V
  • Memory Size
  • 1kB EEPROM 160kB SRAM
  • Protocol
  • 802.11b/g
  • Power - Output
  • 17dBm
  • RF Family/Standard
  • WiFi
  • Sensitivity
  • -96dBm
  • Data Rate (Max)
  • 54Mbps
  • Serial Interfaces
  • SDIO, SPI, UART
  • Current - Receiving
  • 60mA
  • Current - Transmitting
  • 15mA
  • Modulation
  • 16QAM, 64QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
  • Sensitivity (dBm)
  • -96 dBm
  • Nominal Supply Voltage (DC)
  • 3.3V
  • Length
  • 7.7mm
  • REACH SVHC
  • No SVHC
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for H&D Wireless AB HDG104-DN-2.

Datasheets:

HDG104-DN-2 Overview


There is also a 44-LQFN Exposed Pad Module package that RF transceiver IC is used to save space on the board. As far as RF transceiver's mounting is concerned, Surface Mount is adopted.TxRx + MCU emerges with transceiver RF's high efficiency and reliability.High reliability is achieved using advanced transceiver RF' packaging Tape & Reel (TR).44 pins are on the transceiver RF circuit board.Surface Mount is the one that mounts transceiver.A voltage doesn't fall below 3V as the minimum supply voltage (Vsup) should be applied to this RF transceiver.RF transceiver operates on the basis of the frequency of 2.4GHz.
