Neutrik NAC3FPX
Manufacturer No:
NAC3FPX
Manufacturer:
Package:
Description:
Connector, Power, Socket Quick Connect Straight
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
NAC3FPX information
Neutrik NAC3FPX technical specifications, attributes, parameters and parts with similar specifications to Neutrik NAC3FPX.
- Type
- Parameter
- Contact Material
- Tin
- Contact Plating
- Gold, Silver
- Mount
- Chassis Mount, Panel
- Number of Pins
- 2
- Housing Material
- Polyamide
- Body Material
- Polyamide
- Voltage Rating (AC)
- 250 V
- Voltage Rating (DC)
- 250 V
- Number of Terminations
- 3
- Termination
- Quick Connect
- Connector Type
- Connector, Power, Socket
- Max Operating Temperature
- 80 °C
- Min Operating Temperature
- -30 °C
- Color
- Black, Yellow
- Gender
- Receptacle
- Orientation
- Straight
- Depth
- 43 mm
- Current Rating
- 20 A
- Number of Contacts
- 3
- Contact Gender
- Female
- Contact Resistance
- 3 m?
- Insulation Resistance
- 100 G?
- Number of Ports
- 1
- Wire/Cable Gauge
- 12 AWG
- Voltage Rating
- 250 V
- Length
- 35.4 mm
- REACH SVHC
- No SVHC
- RoHS Status
- RoHS Compliant
- Flammability Rating
- UL94 V-0
- Ratings
- IP65
Download datasheets and manufacturer documentation for Neutrik NAC3FPX.
Datasheets:
NAC3FPX Overview
The product comes in a package of Connector, Power, Socket.2 pins are present on the device.Use it when the temperature is below 80 °C.Temperatures below -30 °C are required for this device to operate.It is mounted by Chassis Mount, Panel.
NAC3FPX Features
3 basic kinds of terminations
NAC3FPX Applications
There are a lot of Neutrik
NAC3FPX Circular Connectors applications.
- Embedded systems
- Datacom
- Communication
- Medical technology
- Military Technology
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
- Telecommunications
- Data Technology
