ST PM6764TR

Manufacturer No:

PM6764TR

Manufacturer:

Package:

VFQFPN-28

Description:

4-/6-phase VR12.5 digital multiphase controller with PMBus™

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PM6764TR information

ST PM6764TR technical specifications, attributes, parameters and parts with similar specifications to ST PM6764TR.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Not Recommended

Ihs Manufacturer
STMICROELECTRONICS

Package Description
VFQFPN-28

Manufacturer Package Code
VFQFPN 28 4x4x1.0

Reach Compliance Code
compliant

ECCN Code
3A991.A.3

HTS Code
8542.39.00.01

Samacsys Manufacturer
STMicroelectronics

Adjustable Threshold
YES

Analog IC - Other Type
SWITCHING CONTROLLER

JESD-30 Code
S-XQCC-N28

Length
4 mm

Number of Channels
1

Number of Functions
1

Number of Terminals
28

Package Body Material
UNSPECIFIED

Package Code
HVQCCN

Package Equivalence Code
LCC28,.16SQ,16

Package Shape
SQUARE

Package Style
CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Seated Height-Max
1 mm

Surface Mount
YES

Terminal Position
QUAD

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Width
4 mm

Download datasheets and manufacturer documentation for ST PM6764TR.

Datasheets:

en.DM00110477.pdf

PM6764TR Description

PM6764TR developed by STMicroelectronics is a type of digital multiphase controller with PMBus?. It is specifically designed to power Intel’s VR12.5 memories where parameters are required to be programmable through a PMBus? interface. All control and power management functions are delivered based on digital technology to maximize flexibility and performance. The digital multiphase controller PM6764TR provides a suite of protection functions against load overcurrent, under/overvoltage, and feedback disconnections.

PM6764TR Features

PM6764: 4-phase compact digital controller

High-performance digital control loop (digital STVCOT?)

Fully configurable through PMBus?

Flexible driver/DrMOS support

Current sense across DCR with calibration

PM6764TR Applications

High current power regulation for VR12.5 based Intel? based microprocessors

DDR memory power regulation for VR12.5-based Intel based systems
