RF Digital Corporation RFD22301

Manufacturer No:

RFD22301

Manufacturer:

RF Digital Corporation

Package:

19-SMD Module

Description:

2.4GHz Bluetooth 2.1V~3.6V SPI, UART Tray Integrated, Chip 8Mbps 4dBm Max Bluetooth v4.0 -93dBm 19-SMD Module

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

RFD22301 information

RF Digital Corporation RFD22301 technical specifications, attributes, parameters and parts with similar specifications to RF Digital Corporation RFD22301.

Type
Parameter

Factory Lead Time
8 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
19-SMD Module

Number of Pins
19

Packaging
Tray

Published
2008

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Max Operating Temperature
75°C

Min Operating Temperature
-25°C

Voltage - Supply
2.1V~3.6V

Frequency
2.4GHz

Operating Supply Voltage
3V

Interface
SPI, UART

Data Rate
8Mbps

Protocol
Bluetooth v4.0

Power - Output
4dBm Max

RF Family/Standard
Bluetooth

Antenna Type
Integrated, Chip

Sensitivity
-93dBm

Serial Interfaces
SPI, UART

Current - Receiving
12mA

Current - Transmitting
12mA

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for RF Digital Corporation RFD22301.

Datasheets:

rfdigitalcorporation-rfd22301-datasheets-4129.pdf

rfdigital-rfd22301-datasheets-3607.pdf

RFD22301 Overview

The RF Transceiver' mounting method adopted is Surface Mount.It is designed to provide optimal performance by utilizing the Tray package.The high power RF Transceiver operation of the system is controlled by 19 pins.It is possible for the RF Transceiver to supply voltages of 2.1V~3.6V.There is 2.4GHz frequency set for the RF Transceiver Module.Many applications make use of this Transceiver , which has Surface Mount mounted.
