CEL UPC8236T6N-E2-A

Manufacturer No:

UPC8236T6N-E2-A

Manufacturer:

CEL

Package:

6-XFDFN Exposed Pad

Description:

17dB ~ 22dB GPS Cut Tape (CT) 1575.42MHz 1.6V~3.3V P1dB:-18dBm 0.8dB 6.2mA Surface Mount

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

UPC8236T6N-E2-A information

CEL UPC8236T6N-E2-A technical specifications, attributes, parameters and parts with similar specifications to CEL UPC8236T6N-E2-A.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
6-XFDFN Exposed Pad

Number of Pins
6

Packaging
Cut Tape (CT)

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Min Operating Temperature
-40°C

Max Power Dissipation
150mW

Voltage - Supply
1.6V~3.3V

Frequency
1575.42MHz

Operating Supply Voltage
3.3V

Number of Channels
1

Operating Supply Current
6.2mA

Nominal Supply Current
6.5mA

Gain
17dB ~ 22dB

RF Type
GPS

Noise Figure
0.8dB

P1dB
-18dBm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for CEL UPC8236T6N-E2-A.

UPC8236T6N-E2-A Overview

A RF type of GPS is provided by the RF amplifier.Using advanced packaging techniques Cut Tape (CT), high reliability is ensured.The RF power Amplifier has been packed in 6-XFDFN Exposed Pad for convenient overseas shipping.You should mount Amplifiers RF in the way of Surface Mount.1.6V~3.3V voltage is available from the Amplifiers RF.If the supply current is operated in the range of 6.2mA or higher, it will provide its performance.On this high power RF Amplifier, there are 6 pins.

UPC8236T6N-E2-A Features

RF Type GPS
1.6V~3.3V voltage
6 pins

UPC8236T6N-E2-A Applications

There are a lot of CEL
UPC8236T6N-E2-A RF Amplifiers applications.

GPS
GLONASS
BeiDou
Galileo
Wireless communications
ISM applications
Wireless infrastructure
Automated test equipment
RF/IF gain control
Microwave Radios
